KK Mini Super ~ 45" RC Sports Model by Dave Boddington ~ Laser-cut Wing RIB & Former SET

Model aircraft

£35.00

KK Mini Super - Laser-cut Rib Set

This is Not a full kit, no plan is included and additional materials will be required to finish the model.

Mini Super. A 75% version of the original Keil Kraft Super 60 by Ernie Webster was designed (developed) by David Boddington with a 48in wingspan.

We now offer Rib sets for all three KK Super 60 size versions: original KK Super 60 (63" span), Mini Super (45" DB version) & Micro Super (25" DB version)

Model specification:

  • Brand:                    Keil Kraft / Aviation Modeller International

  • Design:                  Dave Boddington (1996)

  • Type:                     Sports RC sport model (1-3 channels

  • Wing span:            48"

  • Engine:                 1.5cc - 2.5cc engines.

The following 31 quality laser-cut parts are included in the box.

  • 22 x wing ribs laser-cut in hand-selected 2.4mm Balsa

  • 3 x ply wing braces laser-cut in 1.5 aircraft ply (Front brace laminated to 3.0mm thickness)

  • 3 F1 Fuselage formers cut in 3.0mm balsa (laminated to achieve 9.0mm thickness)

  • 3 fuselage formers cut in 3.0 liteply

  • Ribs are cut with small vents to reduce 'ballooning' when film-covered

  • No building plan is included. This is not a complete kit

The plan for this model can be purchased via this direct link:

Free download plan here: https://outerzone.co.uk/plan_details.asp?ID=7900

You can also view all models in our eBay store at www.ebay.co.uk/str/skyhighrc

Price includes FREE P&P (UK only / not signed for).

Please read the rest of the description below carefully as this is not a complete kit.

  • The box contains laser-cut ribs/parts only.

  • This is not a complete model kit.

  • Additional materials will be required to complete the model.

  • All photos are for illustration purposes only.

  • The photo of laser-cut parts (blue background) shows exactly what you will receive in the box

  • Building plans are not included

  • Plans can be obtained from https://model-plans.co.uk/
